Establishing a Robust Human Factors Engineering Process in Development


2019-bl-robust-human-factors-engineering-process-page-image
The U.S. Food and Drug Administration (FDA) describes human factors engineering as “The application of knowledge about human behavior, abilities, limitations, and other characteristics of medical device users to the design of medical devices including mechanical and software driven user interfaces, systems, tasks, user documentation, and user training to enhance and demonstrate safe and effective use. Human Factors Engineering and Usability Engineering can be considered to be synonymous.”

I view human factors engineering (HFE) as being an essential part of User Experience Design (UXD) and a major component of ensuring that human well‐being and system performance are optimized through three main categories:

  • Testing
  • Evaluation
  • Research

#HumanFactorsEngineering is an essential part of user experience design and a major component in ensuring human well-being and system performance are optimized, says @MCMasterControl http://bit.ly/2GpVl5K

Core HFE Objectives

These methodologies aid in assessing behaviors, abilities, limitations and other characteristics. The difference between these methodologies should be clearly defined. Team members outside of the field will request a usability test when research or evaluation may be more appropriate. Be sure you understand their product question before committing to a specific methodology.

The main objectives of HFE are:

  • Increased safety;
  • Reduced errors;
  • Increasing the ease of use and desirability of products;
  • Ensuring products are compliant with regulations:
    • IEC‐62366
    • FDA Human Factors Guidance

Notice that safety is listed as the first objective. Many people believe that the main focus of a human factors engineer is usability. While this is true in consumer products, in medical, the priority is safety. Take the example of a power button. Often times, the power button on a medical device will be placed in the back, in a lower harder to reach corner, which is clearly not user-friendly. The reason for this is to avoid accidental shut down. Even when a power button is on the front of a device, there is typically a requirement to press and hold the button for 3 seconds in order to avoid accidental powering off.

Creating an HFE Process

white paper icon

Enjoying this article? You may also enjoy this White Paper:

Get Ready: Why Designing Quality Into Your Product is Key to 510(k) Success

Download Free White Paper

A good HFE process should be:

1. Ongoing: The process is not a one‐time test that finds all design flaws.

2. Measurable: The process should include metrics, defined and observable so that improvements to your product and ROI are measurable.

3. Iterative: Testing and designing involves repetition in order to refine the design and usability.

4. Integrated: The HFE process should be integrated into product development. It is the key to ensuring you are making data-driven design decisions throughout the development life cycle.

Assuming you have established an HFE process that includes the items above, how do you go from a checklist of items to complete a robust process? The word “robust” is thrown around a lot but nailing down a definition of what this means can be difficult. It’s a buzzword that feels abstract. To tighten the definition and concept here are a few items to consider:

  • Is HF considered a core competency at your company? If not, then it will be hard to be robust.
  • How do you make HFE a core competency?

Start With Awareness and Education

For example, at one company I worked for, my task was to start an HFE division. Over a period of five months, I was able to get involved with the product development process training offered to all functions throughout the company. Over that five-month period, I presented to 513 individuals spanning the U.K.,  the U.S. and Singapore. Individuals included in this training came from a variety of functional areas such as marketing, customer support, electrical engineering, mechanical engineering, Program Managers and Core Team Leads. What this meant for me – every time a new project would arise, someone from one of these functions would contact me to request support from my team.

robust for Tressa
The above figure outlines some important features of a robust HFE process. The first item, awareness and education, is reflected above; the remaining are equally necessary and valuable:


Collaboration
with multifunctional groups is critical to the success of HFE being accepted and understood as a valuable part of the company skill sets.

Strong documentation. Some of the most important information in history is in the form of a document. Historical documentation comes in many forms, cave paintings, stone carvings, maps and diaries. Documentation takes time – and in some cases, you may view it as wasted effort because you may think no one will take the time to read it anyway. Before you jump to this assumption, consider the items that should be documented in HFE activities.

  • Critical/Essential tasks
  • Location/Environment
  • Intended users
  • Moderator guides
  • Participant handouts
  • Product for testing
  • Requirements under test
  • Functions being tested
  • Hazards being tested
  • Mitigations under test
  • Effectiveness of the mitigations
  • Qualitative and quantitative data
  • Overall outcome
  • Recommendations and next steps

All of this information is important and can feed into any of the following:

  • Traceability matrixes for design decisions;
  • Patents;
  • Implementation of test results;
  • And proof of successful mitigations as they pertain to critical tasks and product safety.

Templates used to document this information as well as increase the robustness of your process and include the following:

  • HFE Plan and Report
  • User Research Plan and Report
  • Formative Usability Test Plan and Report
  • Human Factors Validation Test Plan and Report
  • Task Analysis
  • User Failure Mode and Effects Analysis/Hazards Analysis
  • Known Use Errors
  • Postmarket Surveillance Research and Reports

Consistent documentation is required – I often hear the phrase,  “If it’s not documented, it didn’t happen.” This is absolutely true, especially when it comes to design traceability, the design history file and a submission to the FDA for 510k of premarket approvals (PMA).

All of these functions help keep tasks on track, teams aligned and expectations clear. Each of these documents may come at different points in the product development process. I have seen the most success in delivering at these stages:

Stage 0 Opportunity Generation: Exploratory Research/User Research Plans and reports.

Stage 1 Concept Definition: HFE Project Plans: Now that you have an understanding of pain points and user needs from the research conducted in stage 0, what are your overall project plans for HFE activities?

Stage 2 Feasibility: Known Use Errors – What do we know is wrong, and how can we fix it?

Stage 3 Design and Development: Use related Hazards Analysis‐ identify mitigations and begin testing them in formative usability tests. After several iterations and once a production equivalent system is ready, create an HFE Validation Test Plan, execute the test and finalize the report.

Stage 4 Launch Preparation: Complete the HFE Engineering Project report. Summarize all activities, identify any deviations from the plan written in Stage 1 and ensure everything in in your project Design History File.

Stage 5 Full Market Release: Conduct postmarket surveillance to ensure safety and usability issues are being tracked and fixed.

Conclusion

HFE processes provide maximum benefit when integrated into the existing product development process as a parallel activity along with other product development functions. Ideally, HFE is applied throughout the development process, starting with concept development activities. However, even if a project is in later stages, it’s better to include analysis at that time, rather than not at all.

#HumanFactorsEngineering processes provide a device manufacturer maximum benefit when integrated into the existing product development process, says @MCMasterControl http://bit.ly/2GpVl5K

At worst, releasing a product without due consideration for HFE could lead to the injury or death of a patient or health care professional. At best, poor attention to HFE could drive business away to competitors, which hurts a company's bottom line.

HFE provides a better user experience and increased ease of use, so even if your organization isn’t a medical device company – it’s good for business.
